NDT1313XW is a new generation of high-resolution 130mm × 130mm wireless dynamic FPD. It adopts 85 μm pixel pitch, and the scintillator adopts DRZ+(GOS)/CSI, with higher image detail expression and endurance.
Industrial wireless dynamic FPD adopts WiFi6 wireless transmission technology and built-in lithium battery power supply.
| NDT1313XW | |||
| Type of Detector | Amorphous Silicon | Frame Rate | 20fps（1X1) 40fps（2X2） |
| Scintillator | CSI/DRZ+(GOS) | Maximum Exposure Window | 10s |
| Pixel Pitch | 85μm | Radiographic Capability Range | 40-320kV |
| Imaging Area | 130mmX130mm | Overall Dimensions | 271mmX196mmX52mm |
| Pixel Matrix | 1536X1536 | Weight | - |
| Image Resolution | 5.8lp/mm | Ingress Protection | IPX0 |
| ADC | 16bit | Power Dissipation | 12W |
| Trigger Mode | Soft | Power Supply | AC/DC |
| Data Interface | Gigabit Network Cable/WiFi | Operate Environment | Temperature:5℃-35℃ Humidity:5%-95%（No Condensation） |
| Storage Environment | Temperature:-20℃-55℃ Humidity:5%-95%（No Condensation） | ||
